ILLUMINATION

• Long lasting,efficient ultra bright white LED lamp heads.

• 1.5 watt(12LEDsx0.125W)per head.

• High performance chrome-plated metallized reflector and plastic lens for optimal light distribution.

• Adjustable LED lamp heads provides optimal center-to- center  spacing.

• Ultra bright,energy efficient,long-lasting white LED provides even,fully illuminated panel.

ELECTRICA

• 120-347V.

• Charge rate/power"ON"LED  indicator  light  and  push-to-test switch for mandated code compliance testing.

• 3.6V Long life,maintenance-free,rechargeable NiCd battery.

• Internal solid-state transfer switch automatically connects  the internal battery to LED board and LED lamp heads for minimum 90-minute emergency illumination.

• Fully automatic solid-state,two rate charger initiates battery charging to recharge a discharged battery in 24 hours.

MOUNTING

• EZ-snap mounting canopy included for top or end mount.

• Universal knockout pattern on back plate for wall mount.

• Field selectable,universal directional indication provided with three (Left,Right and No Arrow)pictogram legends.

HOUSING

• Injection-molded,engineering grade,5VAflame retardant, high-impact resistant,thermoplastic in white or black finish.

WARRANTY/LISTING

• Five year warranty on all electronics and housing.Battery prorated for fi ve years.

• Meets UL924,NFPA 101 Life Safety Code,NEC,OSHA, Local and State Codes.

• CSA listed for damp locations  (0℃-50℃.).

• Meets or exceeds CSA C22.2 No.141.15 standard requirements for Emergency lighting equipment.
